SCI100-Pro 5L Rotary Evaporator, Vertical Coiled Condenser, Motorized Lift - 611132019999

$4,736.00
Get Financing
Add to wishlist
Add to compare
SKU: R7800-1
California prop 65
Description

Description

  • Key performance benefit: The SCI100-Pro 5L Rotary Evaporator offers precise control over distillation processes, with a digital display that shows rotation speed and heating temperature. The wide temperature range from room temperature to 180°C enables versatile applications and ensures efficient solvent removal.
  • Material & construction: Constructed with chemical-resistant PTFE seals and patented pressure springs, the evaporator ensures excellent sealing and durability. The patented condenser provides a substantial cooling surface of 1500 cm², enhancing cooling efficiency and reliability.
  • Risk reduction/compliance benefit: The automatic motor lift feature ensures the evaporating flask is safely lowered to a secure position in the event of a power failure, minimizing risk and potential damage. This safety feature is critical for maintaining operational integrity.
  • Protection level: The unit includes an overheating protection temperature set at 220°C, safeguarding both the equipment and the user. The precise temperature control and adjustable safety circuit further enhance operational safety, complying with high safety standards.
  • Comfort & usability: The SCI100-Pro is designed for ease of use with an intuitive LCD that provides clear information on speed, temperature, and time. The quick-release connectors and ejection mechanism make flask removal straightforward and efficient.
  • Safety & compliance assurance: The rotary evaporator is equipped with a patented double-spring PTFE sealing ring, providing excellent sealing performance. It also features a remote function for PC control and data transmission, ensuring compliance with modern laboratory standards.

Recommended For

  • Solvent removal in chemical labs
  • Pharmaceutical compound processing
  • Essential oil extraction
  • Academic research laboratories
  • Food and beverage testing
  • Biotechnology applications

Primary Industries

  • Chemical manufacturing
  • Pharmaceutical production
  • Food and beverage industry
  • Academic research
  • Biotechnology sector

Standards and Certifications

  • IP20 Protection Class
SHOW MORE

Properties

Motor Type Brushless DC Motor
Speed Range 20-280rpm
Display LCD (speed, temperature, time)
Clockwise and Anti-clockwise Yes
Heating Temperature Range Room temp. to 180°C
Control Accuracy ± 1°C
Heating Power 1300W
Stroke Displacement Automatic 150mm
Timer Yes
Time Setting Range 1-999min
Dimension [DxWxH] 465x467x583mm
Weight 15kg
Permissible Ambient Temperature 5-40°C
Permissible Relative Humidity 80%RH
Protection Class IP20
USB Interface Yes
Voltage/Frequency 110V, 60 Hz
Power 1400 W
Reviews

FAQs

How is the SCI100-Pro 5L Rotary Evaporator installed in a laboratory setting?

Installation of the SCI100-Pro is straightforward. Ensure a stable, level surface for placement. Connect the unit to a power source matching its voltage requirements (110V, 60 Hz). Attach the necessary glassware and ensure all connections are secure. Follow the user manual for specific assembly instructions and safety checks before operation.

What maintenance is required to keep the SCI100-Pro running efficiently?

Regular maintenance includes checking and replacing PTFE seals as needed, ensuring the condenser is clean and free from blockages, and verifying the motor lift mechanism operates smoothly. Periodically inspect electrical connections and perform a general cleaning of the unit to prevent residue buildup.

Is the SCI100-Pro compatible with other laboratory equipment?

The SCI100-Pro is designed to integrate seamlessly with standard laboratory setups. Its USB interface allows for PC control and data transmission, making it compatible with various data logging and control systems. Ensure compatibility with existing lab equipment by consulting the technical specifications.

What warranty is provided with the SCI100-Pro 5L Rotary Evaporator?

The SCI100-Pro comes with a 2-year warranty covering parts and labor for manufacturing defects. This warranty ensures peace of mind and support in case of any issues. For detailed warranty terms and conditions, refer to the product documentation or contact customer support.

Are there any accessories available for the SCI100-Pro?

Yes, several accessories are available to enhance the SCI100-Pro's functionality. These include additional glassware sets, replacement seals, and specialized condensers. For a complete list of compatible accessories, consult the product catalog or contact the supplier directly.
